Tropical Geography ›› 2023, Vol. 43 ›› Issue (1): 88-102.doi: 10.13284/j.cnki.rddl.003612
Previous Articles Next Articles
Ping Wang(), Xianneng Wang(
), Anfeng Lai
Received:
2022-07-23
Revised:
2022-09-24
Online:
2023-01-05
Published:
2023-02-03
Contact:
Xianneng Wang
E-mail:368210284@qq.com;1735150767@qq.com
CLC Number:
Ping Wang, Xianneng Wang, Anfeng Lai. Characteristics and Causal Mechanism of Topsoil Slip in Ductile Shear Zone of the Shanwei Section of the Lianhuashan Fault Zone[J].Tropical Geography, 2023, 43(1): 88-102.
Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks
Table 2
Comparison between compressive strength of rock in Houmen Ductile shear zone and original rock
地层岩性 | 地点 | 部位 | 岩性 | 饱和抗压强度/MPa | 变形后岩石强度与原岩的比值 |
---|---|---|---|---|---|
J2+3r 凝灰岩 | 太平岭核电站一期工程边坡 | 原岩带 | 中风化凝灰岩 | 46.1 | — |
微风化凝灰岩 | 119.2 | — | |||
鲘门民新村三堆石1#边坡 | 鲘门韧性剪切带 | 中风化千糜岩 | 16.2 | 0.35 | |
微风化千糜岩 | 38.4 | 0.32 | |||
2#边坡 | 鲘门韧性剪切带 | 微风化千糜岩 | 36.4 | 0.31 | |
J1js 泥质岩 | 河海大道(小漠狮山) | 原岩带 | 中风化泥质岩 | 17.7 | — |
微风化泥质岩 | 39.6 | — | |||
通港大道(小漠云新村) | 鲘门韧性剪切带 | 中风化构造片岩 | 6.7 | 0.38 | |
微风化构造片岩 | 23.5 | 0.59 | |||
红海大道(小漠虎坑尾山) | 鲘门韧性剪切带 | 中风化千糜岩 | 15.2 | 0.86 | |
微风化千糜岩 | 29.2 | 0.74 |
Table 5
Results of information quantity model in Ductile shear zone of SSCZ
影响 因素 | 条件 | 分类号 | 滑塌 个数 | 滑塌 总数 | 栅格 数量 | 栅格 总数 | 信息量值 |
---|---|---|---|---|---|---|---|
变形 程度 | 强烈 | 1 | 995 | 1 614 | 394 399 | 1 270 773 | 0.69 |
中等 | 2 | 568 | 1 614 | 699 692 | 1 270 773 | -0.45 | |
弱 | 3 | 51 | 1 614 | 176 682 | 1 270 773 | -1.48 | |
滑塌 距断 层的 距离/m | 0~50 | 1 | 282 | 1 614 | 156 204 | 1 266 952 | 0.35 |
50~200 | 2 | 801 | 1 614 | 402 966 | 1 266 952 | 0.44 | |
200~500 | 3 | 428 | 1 614 | 439 657 | 1 266 952 | -0.27 | |
500~1 000 | 4 | 91 | 1 614 | 235 015 | 1 266 952 | -1.19 | |
>1 000 | 5 | 12 | 1 614 | 33 110 | 1 266 952 | -1.26 | |
地貌 单元 | 低山 | 1 | 127 | 1 614 | 252 923 | 1 266 952 | -0.93 |
高丘陵 | 2 | 1127 | 1 614 | 457 124 | 1 266 952 | 0.66 | |
低丘陵 | 3 | 341 | 1 614 | 147 944 | 1 266 952 | 0.59 | |
台地 | 4 | 19 | 1 614 | 139 383 | 1 266 952 | -2.23 | |
坡度/(°) | 0~15 | 1 | 33 | 1 614 | 489 227 | 1 265 411 | -2.94 |
≥15~25 | 2 | 136 | 1 614 | 247 965 | 1 265 411 | -0.84 | |
≥25~35 | 3 | 430 | 1 614 | 279 060 | 1 265 411 | 0.19 | |
≥35~45 | 4 | 778 | 1 614 | 204 945 | 1 265 411 | 1.09 | |
≥45 | 5 | 237 | 1 614 | 44 214 | 1 265 411 | 1.44 | |
坡向 | 北 | 1 | 52 | 1 614 | 108 574 | 1 143 893 | -1.08 |
北东 | 2 | 133 | 1 614 | 118 412 | 1 143 893 | -0.23 | |
东 | 3 | 334 | 1 614 | 150 002 | 1 143 893 | 0.46 | |
南东 | 4 | 367 | 1 614 | 188 253 | 1 143 893 | 0.32 | |
南 | 5 | 333 | 1 614 | 186 995 | 1 143 893 | 0.23 | |
南西 | 6 | 219 | 1 614 | 156 972 | 1 143 893 | -0.01 | |
西 | 7 | 116 | 1 614 | 123 087 | 1 143 893 | -0.40 | |
北西 | 8 | 60 | 1 614 | 111 598 | 1 143 893 | -0.96 | |
原岩 工程 地质 岩组 | B1 | 2 | 203 | 1 614 | 185 769 | 1 266 891 | -0.15 |
B2 | 3 | 939 | 1 614 | 205 837 | 1 266 891 | 1.28 | |
B3 | 4 | 7 | 1 614 | 9 734 | 1 266 891 | -0.57 | |
C | 5 | 2 | 1 614 | 32 239 | 1 266 891 | -3.02 | |
D1 | 6 | 233 | 1 614 | 339 563 | 1 266 891 | -0.62 | |
D2 | 7 | 227 | 1 614 | 128 397 | 1 266 891 | 0.33 | |
斜坡 结构 类型 | 顺向坡 | 1 | 548 | 1 614 | 190 785 | 1 012 834 | 0.59 |
斜向坡 | 2 | 544 | 1 614 | 263 208 | 1 012 834 | 0.26 | |
横向坡 | 3 | 385 | 1 614 | 296 147 | 1 012 834 | -0.20 | |
逆向坡 | 4 | 132 | 1 614 | 225 706 | 1 012 834 | -1.00 | |
块状岩坡 | 5 | 5 | 1 614 | 36 988 | 1 012 834 | -2.47 |
成玉祥,张卜平,唐亚明.2021. 溯源侵蚀引发的拉裂-倾倒型黄土崩塌形成机制. 中国地质灾害与防治学报,32(5):86-91. | |
Cheng Yuxiang, Zhang Bupingn and Tang Yaming. 2021. The Mechanism of Bending-Toppling Loess Collapse Caused by Headward Erosion. The Chinese Journal of Geological Hazard and Control, 32(5): 86-91. | |
冯文凯,贾邦中,吴义鹰,吴钟腾,白慧林. 2022. 低山丘陵区典型滑坡-泥石流链生灾害特征与成灾机理. 中国地质灾害与防治学报,33(1):35-44. | |
Feng Wenkai, Jia Bangzhong, Wu Yiying, Wu Zhongteng and Bai Huilin. 2022. Characteristics and Mechanism of Landslide-Debris Flow Chain Disaster in Low Mountain and Hilly Terrain. The Chinese Journal of Geological Hazard and Control, 33(1): 35-44. | |
候泉林. 2020. 高等构造地质学:第三卷·专题知识与实践. 北京:科学出版社. | |
Hou Quanlin. 2020. Advanced Structural Geology: Volume 3·Special Knowledge and Practice. Beijing: Science Press. | |
胡海涛,易明初,向祖庭. 1987. 广东核电站规划选址区域稳定性分析与评价. 北京:档案出版社. | |
Hu Haitao, Yi Mingchu and Xiang Zhuting. 1987. Regional Stability Analysis and Evaluation of Guangdong Nuclear Power Plant Planning and Site Selection. Beijing: Archives Publishing House. | |
黄广蓬,苏助,林树苓. 2005. 海丰县志. 广州:广东人民出版社. | |
Huang Guangpeng, Su Zhu and Lin Shuling. 2012. Haifeng County annals. Guangzhou: Guangdong People's Publishing House. | |
李静荣,徐力峰,罗秋宏. 2021. 深圳市深汕特别合作区区域地质调查报告(比例尺:1∶50 000). 广州:广东有色工程勘察设计院. | |
Li Jingrong, Xu Lifeng and Luo Qiuhong. 2021. Regional Geological Survey Report of the Shenzhen Shantou Special Cooperation Zone (1:50 000). Guangzhou: Guangdong Nonferrous Metals Engineering Investigation Design Institute. | |
李俊,陈宁生,赵苑迪. 2018. 滑坡类泥石流稀化判别模型—以西昌市官坝河为例. 中国地质灾害与防治学报,29(6):8-14. | |
Li Jun, Chen Lingsheng and Zhao Yuandi. 2018. The Model of Dilution Process for Landslides Triggered Debris Flows: A Case Study in Guanba River around Xichang City. The Chinese Journal of Geological Hazard and Control, 29(6): 8-14. | |
李文辉,邓飞,邵小阳. 2021. 广东海丰县梅陇镇—惠东县吉隆镇一带海丰断裂带的地质特征. 华南地震,41(4):27-37. | |
Li Wenhui, DengFei, Shao Xiaoyang. 2021. Geological Characteristics of Haifeng Fault Zone in Meilong Town, Haifeng County-Jilong Town, Huidong County, Guangdong Province. South China Journal of Seismology, 41(4): 27-37. | |
李忠泉,刘顺. 2010. 构造地质学. 北京:地质出版社. | |
Li Zhongquan and Liu Shun. 2010. Structural Geology. Beijing: Geological Publishing House. | |
刘天绍,刘孙俊,杨玺,陈劲,张超. 2018. 1951—2015影响广东沿海台风的统计分析. 海洋预报,35(4):68-74. | |
Liu Tianshao, Liu Shunjun, Yang Xi, Chen Jing and Zhang Chao. 2018. Statistical Analysis of the Typhoon Influencing Guangdong Province during 1951-2015. Marine Forecasts, 35(4): 68-74. | |
陆泌锋,邓辉,郝浩,李安润,王浪. 2019. 韧性剪切带和蚀变岩体对边坡开挖稳定性的影响. 人民长江,50(11):123-129. | |
Lu Bifeng, Deng Hui, Hao Hao, Li Anrun and Wang Lang. 2019. Influence of Ductile Shear Zone and Altered Rock Mass on Excavation Stability of Slope. Yangtze River, 50(11): 123-129. | |
陆泌锋,邓辉,郝浩,李安润,李万才. 2020. 某水电站韧性剪切带的发育特征及边坡开挖变形响应研究. 人民珠江,41(1):7-12,81. | |
Lu Bifeng, Deng Hui, Hao Hao, Li Anrun and Li Wancai. 2020. Study on the Development Characteristics of Ductile Shear Zone and Deformation Response of Slope Excavation in a Hydropower Station. Pearl River, 41(1): 7-12, 81. | |
吕佼佼,范文,高徐军,张友科. 基于CiteSpace的浅层滑坡文献计量分析. 中国地质灾害与防治学报,32(1):43-49. | |
Lu Jiaojiao, Fan Wen, Gao Xujun and Zhang Youke. 2021. Metrological Analyses on Literatures of Topsoil Slips Using CiteSpace Software. The Chinese Journal of Geological Hazard and Control, 32(1): 43-49. | |
潘建中,毛维新,邹斌. 2012. 广东省水文志. 北京:中国水利水电出版社. | |
Pan Jianzhong, Mao Weixin and Zou Bing. 2012. Hydrology of Guangdong Province. Beijing: China Water&Power Press. | |
邱元禧,邱津松,李建超,钟宏平. 1991. 广东莲花山断裂带中、新生代多期复合变形变质带的基本特征及其形成机制的探讨. 中国地质科学院地质力学研究所所刊,(1):93-106. | |
Qiu Yuanxi, Qiu Jinsong, Li Jianchao and Zhong Hongping. 1991. Deformational and Metamorphic Features of Lianhuashan Fault Zone during Meso-Cenozoic Time and Mechanism of Their Formation. Bulletin of the Institute of Geomechanics CAGS, (1): 93-106. | |
深圳市深汕特别合作区住房建设和水务局. 2021. 深圳市深汕特别合作区水土保持规划(2020-2035年). (2021-09-01)[2022-05-18]. http://www.szss.gov.cn/gkmlpt/content/9/9100/mpost_9100982.html#19614 | |
Housing Construction and Water Bureau of Shanwei Special Cooperation Zone in Shenzhen. 2021. Water and Soil Conservation Planning of Shanwei Special Cooperation Zone in Shenzhen (2020-2035). (2021-09-01) [2022-05-18]. http://www.szss.gov.cn/gkmlpt/content/9/9100/mpost_9100982.html#19614 | |
王建鹏. 2013. 山区隧道穿越韧性剪切带的地质条件探讨. 工程地质学报,21(3):377-384. | |
Wang Jianpeng. 2013. Geological Conditions of Ductile Shear Zone Exposed by Mountain Tunnel. Journal of Engineering Geology, 21(3): 377-384. | |
王浪,丁军浩,邓辉,王劲翔,涂国祥. 2019. 韧性剪切带和蚀变岩体对坡体卸荷特征影响分析.长江科学院院报,36(6):93-98,105. | |
Wang Lang, Ding Junhao, Deng Hui, Wang Jingxiang and Tu Guoxiang. 2019. Influences of Ductile Shear Zone and Altered Rock Mass on Characteristics of Slope Unloading. Journal of Yangtze River Scientific Research Institute, 36(6): 93-98, 105. | |
汪礼明,王军,王核,卜安,李莎莎,钱龙兵,王玮. 2018. 粤东莲花山断裂带动力变质作用与动力变质热液成矿. 大地构造与成矿学,42(5):908-917. | |
Wang Liming, Wang Jun, Wang He, Bu An, Li Shasha, Qian Longbing ang Wang Wei. 2018. Dynamic Metamorphism Origin for the Tin-Copper Polymetallic Mineralization in the Lianhuashan Fault, Eastern Guangdong Province. Geotectonica et Metallogenia, 42(5): 908-917. | |
王运生,苏毅,冯卓,吴德超,王道永. 2022. 泸定韧性剪切带泸定段及其工程效应. 地球科学,47(3):794-802. | |
Wang Yunsheng, Su Yi, Feng Zhuo, Wu Dechao and Wang Daoyong. 2022. Luding Section of Luding Ductile Shear Zone and Its Engineering Effects. Earth Science, 47(3): 794-802. | |
伍学恒,宋艳芳,魏刚锋. 2013. 韧性剪切带对安康市石狮村滑坡的控制作用. 地质论评,59(增刊1):1155-1156. | |
Wu Xueheng, Song Yanfang and Wei Gangfeng. 2013. Control Effect of Ductile Shear Zone on Shishi Village Landslide in Ankang City. Geological Review, 59(S1): 1155-1156. | |
殷跃平,张作辰,张茂省,郑万模,黄波林. 2016. 滑坡防治工程勘查规范 GB/T 32864—2016. 北京:中国标准出版社. | |
Yin Yaoping,Zhang Zhuochen,Zhang Maosheng, Zheng Wanmo and Huang Bolin. 2016. Code for Geological Investigation of Landslide Preventio GB/T 32864—2016. Beijing: Standards Press of China. | |
张文高,王晓虎,陈正乐,丁志磊,周荣德,胡文杰. 2020. 广东莲花山断裂带韧性剪切带变形特征及其与成矿的关系. 中国地质,47(4):932-943. | |
Zhang Wengao, Wang Xiaohu, Chen Zhengle, Ding Zhilei, Zhou Rongde and Hu Wenjie. 2020. The Deformation Characteristics of Ductile Shear Zone and Its Relationship with Mineralization in Lianhuashan Fault Zone, Guangdong Province. Geology in China, 47(4): 932-943. | |
Zhang Yong, Chen Ningsheng and Liu Mei. 2020. Debris Debris Flows Originating from Colluvium Deposits in Hollow Regions during a Heavy Storm Process in Taining, Southeastern China. Landslides, 17(2): 335-347. | |
张钟远,徐世光,李超,管晓琪,李微,邓胜,郑笑秋. 2022. 基于GIS和加权信息量模型的绿春县城地质灾害易发性评价. 地质灾害与环境保护,33(1):37-43. | |
Zhang Zhongyuan, Xu Shiguang, Li Chao, Guan Xiaoqi, Li Wei, Deng Sheng and Zheng Xiaoqiu. 2022. Evalution of Geological Hazard Susceptibility in Luchun County Based on GIS and Weighted Information Model. Journal of Geological Hazards and Environment Preservation, 33(1): 37-43. | |
钟贻军. 海丰梅陇地区地震危险性讨论. 1994. 华南地震,14(2):37-43. | |
Zhong Yijun. 1994. Disscussing on Seismic Risk in Meilong Area of HaiFeng. South China Journal of Seismology, 14(2): 37-43. | |
邹和平,王建华,丘元禧. 2000. 广东南澳和莲花山韧性剪切带40Ar/39Ar年龄及其地质意义. 地球学报,21(4):356-364. | |
Zou Heping, Wang Jianhua and Qiu Yuanxi. 2000. 40Ar/39Ar ages of the Nan'ao Shear Zone and the Lianhuashan Shear Zone in Guangdong Province and Their Geological Significanc. Acta Geoscientica Sinica, 21(4): 356-364. | |
庄文明,刘建雄,李文辉. 2003. 中华人民共和国区域地质调查报告(比例尺:1∶250 000)香港幅(F50C002001). 广州:广东省地质调查院. | |
Zhuang Wenming, Liu Jianxiong and Li Wenhui. 2003. Regional Geological Survey Report of the People's Republic of China (1:250 000) Hong Kong Amplitude (F50C002001). Guangzhou: Guangdong Geological Survey Institute. |
